Radiola 44 AC AR-594-A
RCA (RCA Victor Co. Inc.); New York (NY)
- Country
- United States of America (USA)
- Manufacturer / Brand
- RCA (RCA Victor Co. Inc.); New York (NY)
- Year
- 1929
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 258772
-
- alternative name: RCA Manufacturing || Victor Talking Machine
- Number of Tubes
- 5
- Main principle
- TRF (Tuned-Radio-Frequency but use of regeneration unknown); Screengrid 1926-1935
- Tuned circuits
- 3 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC) / 25 to 40 cycles, 105-125 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Material
- Wooden case
- from Radiomuseum.org
- Model: Radiola 44 AC AR-594-A - RCA RCA Victor Co. Inc.; New
- Shape
- Tablemodel, Box - most often with Lid (NOT slant panel).
- Dimensions (WHD)
- 26 x 10.5 x 11.25 inch / 660 x 267 x 286 mm
- Notes
-
The RCA Radiola 44 is an AC operated, 5 tube BC band receiver. This version has a different power transformer that operates with 25-40 cycle AC power.
This model has two versions, one operating from 50-60 cycle AC power and the other operating from 25-40 cycle AC power.
- Literature/Schematics (1)
- Rider's Perpetual, Volume 1 = 1931/1934 (1919 to 1931)
- Literature/Schematics (2)
- RCA Victor Service Notes "Red Book" Series
- Author
- Model page created by George Papaiz. See "Data change" for further contributors.
