Radiola 80 3 knobs (w/o tone control)
RCA (RCA Victor Co. Inc.); New York (NY)
- Country
- United States of America (USA)
- Manufacturer / Brand
- RCA (RCA Victor Co. Inc.); New York (NY)
- Year
- 1930/1931
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 54667
-
- alternative name: RCA Manufacturing || Victor Talking Machine
By courtesy of William Kendrick, USA
By courtesy of William Kendrick, USA
Italian ad
1930 RCA Radiola color ad.
Advertisement in Italy
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 9
- Main principle
- Superhet with RF-stage; ZF/IF 175 kHz
- Tuned circuits
- 10 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC) / 105-125 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Power out
- 3 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Radiola 80 [3 knobs ] - RCA RCA Victor Co. Inc.; New
- Shape
- Console, Lowboy (legs < 50 %).
- Dimensions (WHD)
- 27.25 x 43 x 14 inch / 692 x 1092 x 356 mm
- Notes
-
Two versions were available, one operating from 50-60 Cycle AC and the other operating from 25-40 Cycle AC.
- Net weight (2.2 lb = 1 kg)
- 22.5 kg / 49 lb 9 oz (49.559 lb)
- Price in first year of sale
- 142.50 $
- External source of data
- Ernst Erb
- Source of data
- The Radio Collector's Directory and Price Guide 1921 - 1965
- Circuit diagram reference
- Rider's Perpetual, Volume 1 = 1931/1934 (for 1919-1931)
- Mentioned in
- Collector's Guide to Antique Radios 4. Edition
- Literature/Schematics (1)
- RCA Victor Service Notes "Red Book" Series (PAGE 1-44 R.C.A.)
- Literature/Schematics (2)
- Rider's Perpetual, Volume 2 = 1932 and before (FROM PAGE 2-89 TO 2-91 R.C.A.)
- Literature/Schematics (3)
- Pre-War Consoles
- Literature/Schematics (4)
- Radiola, the golden Age of RCA
- Other Models
-
Here you find 5126 models, 3229 with images and 4161 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from RCA (RCA Victor Co. Inc.); New York (NY)
Collections
The model Radiola is part of the collections of the following members.
Forum contributions about this model: RCA RCA Victor Co.: Radiola 80
Threads: 1 | Posts: 3
I just posted what looks like a Radiola 80 with FOUR KNOBS in front. Is anyone familiar with this? The cabinet and chassis look identical, excluding the additional knob on bottom.
Paul Kasindorf, 18.Dec.13
