RE-16A Ch= R-7A
RCA (RCA Victor Co. Inc.); New York (NY)
- Country
- United States of America (USA)
- Manufacturer / Brand
- RCA (RCA Victor Co. Inc.); New York (NY)
- Year
- 1931
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 54705
-
- alternative name: RCA Manufacturing || Victor Talking Machine
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 8
- Main principle
- Superhet with RF-stage; ZF/IF 175 kHz
- Wave bands
- Broadcast only (MW).
- Details
- Record Player (perh.Changer)
- Power type and voltage
- Alternating Current supply (AC) / 105-125 Volt
- Material
- Wooden case
- from Radiomuseum.org
- Model: RE-16A Ch= R-7A - RCA RCA Victor Co. Inc.; New
- Shape
- Console with any shape - in general
- Notes
- Not to be confused with RE-16 !
Uses the standard R-7A chassis, plus phonograph plus speaker.
- External source of data
- Ernst Erb
- Circuit diagram reference
- Rider's Perpetual, Volume 4 = ca. 1934 and before
- Literature/Schematics (1)
- RCA Victor Service Notes "Red Book" Series
