• Country
• United States of America (USA)

• Manufacturer / Brand
• RCA (RCA Victor Co. Inc.); New York (NY)

• Year
• 1968

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 96374

• • alternative name: RCA Manufacturing || Victor Talking Machine

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 5

• Semiconductors

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)

• Tuned circuits
• 5 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Alternating Current supply (AC) / 60 cycles, 110 - 120 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: RLD 25Y "The Dreamette" - RCA RCA Victor Co. Inc.; New

• Shape
• Tablemodel with Clock ((Alarm-) Clock Radio).

• Notes

• The RCA RLD 25Y is an AC operated 5 transistor AM clock radio.  The AM frequency tuning range is 540 to 1600kHz.  Uses silicon rectifier in power supply. Has built-in loop antenna. Power consumption is 9 Watts.

  The following models use the same printed circuit board and schematic:

  Model	Clock	Cabinet Colors
  RLA 19G	No	Olive/White
  RLA 19T	No	Brown/White
  RLD 25Y	Yes	White/Black



• Circuit diagram reference
• Beitman Radio Diagrams Vol. 27, 1967-69 (last vol.)

• Mentioned in
• - - Manufacturers Literature (RCA Radio Service Data Datasheet - File 1968 No. 22)

• Literature/Schematics (1)
• Beitman Radio Diagrams, vol. 27, 1967-69 (last volume) (Page 111)

• Author
• Model page created by Egon Penker. See "Data change" for further contributors.
