• Country
• United States of America (USA)

• Manufacturer / Brand
• RCA (RCA Victor Co. Inc.); New York (NY)

• Year
• 1933 ?

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 54811

• • alternative name: RCA Manufacturing || Victor Talking Machine

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 2

• Valves / Tubes
• 30 30

• Power type and voltage
• Dry Batteries / 4.5 & 22.5 Volt

• Material
• Metal case

• from Radiomuseum.org
• Model: Signal Generator TMV-97-A - RCA RCA Victor Co. Inc.; New

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 245 x 165 x 115 mm / 9.6 x 6.5 x 4.5 inch

• External source of data
• Ernst Erb

• Circuit diagram reference
• Rider's Perpetual, Volume 5 = ca. 1934 and before

• Literature/Schematics (1)
• RCA Victor Service Notes "Red Book" Series

• Other Models

• Here you find 5132 models, 3235 with images and 4167 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from RCA (RCA Victor Co. Inc.); New York (NY)
