- Country
- Canada
- Manufacturer / Brand
- RCA Victor (International), Montreal
- Year
- 1935 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 295157
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 8
- Main principle
- Superhet with RF-stage; ZF/IF 460 kHz; 3 AF stage(s)
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and 2 x Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 105 to 125 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- from Radiomuseum.org
- Model: 340A - RCA Victor International,
- Notes
-
The Canadian RCA-Victor model 340A is an 8-tube radio. Covers longwave, standard broadcast and shortwave in 2 ranges. For 25 or 60 Hz depending on nameplate rating.
Same chassis as Canadian RCA-Victor models 143 and 242.
- Literature/Schematics (1)
- - - Manufacturers Literature (RCA Victor Service Manual (Montreal, Canada))
- Author
- Model page created by Tom Seeger. See "Data change" for further contributors.
