- Country
- Canada
- Manufacturer / Brand
- RCA Victor (International), Montreal
- Year
- 1948/1949
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 183143
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast plus 2 Short Wave bands.
- Power type and voltage
- Alternating Current supply (AC) / 117 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 inch = 20.3 cm
- Power out
- 2 W (3 W max.)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 51 - RCA Victor International,
- Shape
- Console, Lowboy (legs < 50 %).
- Dimensions (WHD)
- 25 x 30.5 x 13 inch / 635 x 775 x 330 mm
- Notes
-
The Canadian RCA Victor model 51 is a 5-tube console radio. Covers standard broadcast and 5.7-13 MHz and 11.6-16 MHz shortwave.
- Circuit diagram reference
- Radio College of Canada
- Literature/Schematics (1)
- Canada schematics RCA Victor page 106,107
- Literature/Schematics (2)
- RCA Service Manual Vol 4 P. 71
- Author
- Model page created by Dirk Taekels. See "Data change" for further contributors.
