7-BT-10K
RCA Victor (International), Montreal
- Country
- Canada
- Manufacturer / Brand
- RCA Victor (International), Montreal
- Year
- 1956 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 301058
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 7
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 3 AF stage(s)
- Tuned circuits
- 5 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Dry Batteries / 9 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Power out
- 0.05 W (unknown quality)
- Material
- Various materials
- from Radiomuseum.org
- Model: 7-BT-10K - RCA Victor International,
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 10 x 6.5 x 3.75 inch / 254 x 165 x 95 mm
- Notes
-
The RCA-Victor model 7-BT-10K is a 7-transistor portable radio. Has a ferrite rod antenna. See also USA model.
- Literature/Schematics (1)
- Radio College of Canada (RCC) (1957 Supplement 39)
- Author
- Model page created by Tom Seeger. See "Data change" for further contributors.
