80MA

RCA Victor; Buenos Aires

Data
Forum
Pictures
Collections

  • Year
  • 1948 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 331404

 Technical Specifications

  • Number of Tubes
  • 8
  • Main principle
  • Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)
  • Tuned circuits
  • 7 AM circuit(s)
  • Wave bands
  • Broadcast plus more than 2 Short Wave bands.
  • Power type and voltage
  • Alternating Current supply (AC) / 210-230 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 8 inch = 20.3 cm
  • Power out
  • 3.45 W (4.5 W max.)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: 80MA - RCA Victor; Buenos Aires
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 550 x 345 x 265 mm / 21.7 x 13.6 x 10.4 inch
  • Notes

  • Wave bands:
    MW = 540 - 1720 kHz
    SW = 2.9 - 22.5 MHz in 5 bands

    El circuito de este modelo es igual al modelo RCA Q34 de Estados Unidos.

  • Net weight (2.2 lb = 1 kg)
  • 15.436 kg / 34 lb 0 oz (34 lb)
  • Author
  • Model page created by Heriberto Tavella. See "Data change" for further contributors.
