• Country
• Canada

• Manufacturer / Brand
• RCA Victor (International), Montreal

• Year
• 1937 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 295257

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 6A7 6D6 75 41 80

• Main principle
• Superheterodyne (common); ZF/IF 460 kHz; 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• Alternating Current supply (AC) / 105 to 125 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 85KA - RCA Victor International,

• Shape
• Console with any shape - in general

• Notes

• The Canadian RCA-Victor model 85KA is a 5-tube console radio for standard broadcast and 6 to 18 MHz shortwave reception. Requires an external wire antenna.

• Literature/Schematics (1)
• - - Manufacturers Literature (RCA Victor Service Manual (Montreal, Canada))

• Author
• Model page created by Tom Seeger. See "Data change" for further contributors.
