• Country
• Canada

• Manufacturer / Brand
• RCA Victor (International), Montreal

• Year
• 1938/1939

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 200497

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 11

• Valves / Tubes
• 6K7 6A8 6J7 6K7 6U5 6H6 6F5 6F5 6F6 6F6 5T4

• Main principle
• Superhet with RF-stage; ZF/IF 455 kHz; 3 AF stage(s)

• Tuned circuits
• 7 AM circuit(s)

• Wave bands
• Broadcast plus more than 2 Short Wave bands.

• Power type and voltage
• Alternating Current supply (AC) / 105-125 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 12 inch = 30.5 cm

• Power out
• 10 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 911K - RCA Victor International,

• Shape
• Console with Push Buttons.

• Dimensions (WHD)
• 28.5 x 41.5 x 14.5 inch / 724 x 1054 x 368 mm

• Notes

• RCA 911K was simultaneously manufactured in Canada and USA. See USA model 911K.

• Mentioned in
• RCA Vol 1 Page 284

• Literature/Schematics (1)
• Radio College of Canada (RCC) (see CGE sheet 38 (model G-11))

• Literature/Schematics (2)
• - - Manufacturers Literature (RCA Service Manual (Montreal, Canada))

• Author
• Model page created by Ashis Mukerjea. See "Data change" for further contributors.
