• Country
• Canada

• Manufacturer / Brand
• RCA Victor (International), Montreal

• Year
• 1939/1940

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 148880

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 8

• Valves / Tubes
• 6SK7 6SA7 6B8 6SC7 6U5 6F6G 6F6G 5Y4G

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)

• Tuned circuits
• 7 AM circuit(s)

• Wave bands
• Broadcast plus more than 2 Short Wave bands.

• Power type and voltage
• Alternating Current supply (AC) / 105-125 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 inch = 30.5 cm

• Power out
• 8 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: A6 - RCA Victor International,

• Shape
• Console with any shape - in general

• Source of data
• -- Original-techn. papers.

• Mentioned in
• Pre-War Consoles (Volume 1939-1940 page 23)

• Author
• Model page created by Ashis Mukerjea. See "Data change" for further contributors.
