- Country
- Canada
- Manufacturer / Brand
- RCA Victor (International), Montreal
- Year
- 1946/1947
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 182169
From a Kijiji advertisement.
From a Kijiji advertisement.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superhet with RF-stage; ZF/IF 455 kHz
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- AC/DC-set / 115 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Power out
- 1 W (1.5 W max.)
- Material
- Bakelite or Plastics (type unknown)
- from Radiomuseum.org
- Model: Master - RCA Victor International,
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Notes
-
Built in loop antenna. Speaker is 4 x 6 inch eliptical. Available in Ivory and brown colour cabinet.
- Circuit diagram reference
- Radio College of Canada
- Literature/Schematics (1)
- Canada schematics RCA Victor page 56
- Literature/Schematics (2)
- RCA Service Manual Vol 4 P. 287
- Author
- Model page created by Dirk Taekels. See "Data change" for further contributors.
