- Country
- Canada
- Manufacturer / Brand
- RCA Victor (International), Montreal
- Year
- 1933/1934
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 226189
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 7
- Main principle
- Superhet with RF-stage; ZF/IF 175 kHz; 2 AF stage(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC)
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: R 49 - RCA Victor International,
- Shape
- Console, Lowboy (legs < 50 %).
- Dimensions (WHD)
- 25.25 x 40.25 x 12.25 inch / 641 x 1022 x 311 mm
- Notes
-
This R 49 is similar with model K-75 by Canadian General Electric. It is a 6-legged lowboy console with stretcher base, with three knobs nearly in line (middle only a little bit lower).
Note: CGE Model K75 is a Victor R49. See RCC, cross reference.
" Radios of Canada by Lloyd Swackkhammer" Quote: RCA in the US was originally formed to be a patent holding company and contracted out the manufacture of their radios to the Westinghouse and General Electric companies. They also followed this procedure in Canada, using the Canadian Westinghouse and Canadian General Electric companies. Many times during this era sets were made with identical chassis, except they used different model numbers for GE, Westinghouse and RCA Victor brands.
- Literature/Schematics (1)
- Radio College of Canada (RCC) (Victor 15 (R49))
- Literature/Schematics (2)
- Radio College of Canada (RCC) (cross reference)
- Author
- Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
