- Country
- Canada
- Manufacturer / Brand
- RCA Victor (International), Montreal
- Year
- 1931 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 294979
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 8
- Main principle
- TRF without regeneration; 2 AF stage(s)
- Tuned circuits
- 5 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Details
- Recording phonogr.-Disc Recorder
- Power type and voltage
- Alternating Current supply (AC) / 105 to 125 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- from Radiomuseum.org
- Model: RE-57 - RCA Victor International,
- Notes
-
The Canadian RCA-Victor model RE-57 is an 8-tube TRF receiver for broadcast reception with built in record player/disk cutter. Requires an external wire antenna. For 25 or 60 Hz depending on nameplate rating. See similar USA model Electrola RE-57.
- Literature/Schematics (1)
- - - Manufacturers Literature (RCA Victor Service Manual (Montreal, Canada))
- Author
- Model page created by Tom Seeger. See "Data change" for further contributors.
