• Country
• Canada

• Manufacturer / Brand
• RCA Victor (International), Montreal

• Year
• 1963 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 309405

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 11

• Valves / Tubes
• 6DT8 6BA6 6DC8 6AU6 6AL5 6BE6 6CG7 6AU6 6AU6 6BQ5 6BQ5

• Main principle
• Superheterodyne (common); ZF/IF 455/10700 kHz; 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)     7 FM circuit(s)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 60 Hz, 117 Volt

• Loudspeaker
• 4 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: SHC764 - RCA Victor International,

• Shape
• Console with any shape - in general

• Notes

• The RCA-Victor model SHC764 is an 11-tube AM/FM console radio with built-in stereo record changer. Has a woofer and tweeter for each channel. Same schematic as model SHC763.

• Literature/Schematics (1)
• Radio College of Canada (RCC) (1963 Supplement 62)
