- Country
- Canada
- Manufacturer / Brand
- RCA Victor (International), Montreal
- Year
- 1935/1936
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 148069
Not original knobs
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 8
- Main principle
- Superheterodyne (common); ZF/IF 460 kHz
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast, Short Wave(s) and Police.
- Power type and voltage
- Alternating Current supply (AC) / 105-125 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: T7-1 - RCA Victor International,
- Shape
- Tablemodel, Tombstone = decorative upright, not cathedral but can have rounded edges.
- Notes
-
The GE Table Model is known as A-70. Equivalent to RCA Victor Table Model T7-1 and RCA Victor Console Model C7-1. Schematic is common for all these 4 models, see RCC Victor-42.
- Circuit diagram reference
- Radio College of Canada
- Mentioned in
- RCC Victor p.42
- Literature/Schematics (1)
- - - Manufacturers Literature (RCA Victor Service Manual (Montreal, Canada))
- Author
- Model page created by Ashis Mukerjea. See "Data change" for further contributors.
