The Madrid DG-463

RCA Victor (International), Montreal

Data
Forum
Pictures
Collections

  • Year
  • 1960 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 319334

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Superheterodyne (common); ZF/IF 460/10700 kHz
  • Wave bands
  • Broadcast, 2 Short Wave plus FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 117 Volt
  • Loudspeaker
  • 4 Loudspeakers
  • Power out
  • 4.5 W (undistorted)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: The Madrid DG-463 - RCA Victor International,
  • Shape
  • Tablemodel with Push Buttons.
  • Dimensions (WHD)
  • 21 x 11 x 9 inch / 533 x 279 x 229 mm
  • Notes

  • The RCA-Victor model DG-463 is a large table top radio for AM/FM and shortwave reception. Has woofer, two tweeters and tuning indicator tube. With bass, treble controls and tone selectors for Music/Speech and Orchesta/Jazz. Phono input. Covers the following ranges:

    Band Selector Frequency
    AM 515 - 1620 kHz
    SW-I 1.8 - 6.1 MHz
    SW-II 5.9 - 19 MHz
    FM 87 - 108 MHz

    Schematic may be close enough to model DM-564 for repair purposes.
