- Country
- Canada
- Manufacturer / Brand
- RCA Victor (International), Montreal
- Year
- 1951 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 299091
From service manual.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 105 to 125 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Power out
- 2.5 W (3.5 W max.)
- Material
- Wooden case
- from Radiomuseum.org
- Model: V405A - RCA Victor International,
- Shape
- Console, Lowboy (legs < 50 %).
- Dimensions (WHD)
- 29.5 x 29.6 x 15.5 inch / 749 x 752 x 394 mm
- Notes
-
The Canadian RCA Victor model V405A is a 5-tube radio / dual record changer combination console. Covers standard broadcast. Has a 6 x 9 eliptical speaker.
Contains model RP-168C changer for 45 rpm disks and model RP200 changer for 78/33 rpm disks. Both use ceramic pickups. Similar to model V405 with the exception of the cabinet design, and the I.F amplifier tube.
For 50 or 60 Hz depending on nameplate rating.
- Literature/Schematics (1)
- RCA Service Manual Vol 5 P. 208
- Author
- Model page created by Tom Seeger. See "Data change" for further contributors.
