- Country
- Canada
- Manufacturer / Brand
- RCA Victor (International), Montreal
- Year
- 1947 ?
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 299562
From service manual.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 2
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Record Player (not changer)
- Power type and voltage
- Alternating Current supply (AC) / 105 to 125 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Power out
- 0.8 W (1.75 W max.)
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: VE22 - RCA Victor International,
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 12.5 x 6.5 x 10 inch / 318 x 165 x 254 mm
- Notes
-
The RCA Victor model VE22 is a 2-tube 78 rpm record player with crystal phono pickup. Has a 4 x 6 inch eliptical speaker. For 25 or 60 Hz depending on nameplate rating.
- Literature/Schematics (1)
- RCA Service Manual Vol 4 P. 33
- Author
- Model page created by Tom Seeger. See "Data change" for further contributors.
