- Country
- Canada
- Manufacturer / Brand
- RCA Victor (International), Montreal
- Year
- 1939/1940
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 152624
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 11
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Wave bands
- Broadcast plus more than 2 Short Wave bands.
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 105-125 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 inch = 30.5 cm
- Power out
- 12 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: VR8-S - RCA Victor International,
- Shape
- Console with Push Buttons.
- Dimensions (WHD)
- 36.25 x 34 x 17 inch / 921 x 864 x 432 mm
- Net weight (2.2 lb = 1 kg)
- 46.8 kg / 103 lb 1.3 oz (103.084 lb)
- Price in first year of sale
- 398.00 USD
- Source of data
- -- Original prospect or advert
- Circuit diagram reference
- Radio College of Canada
- Mentioned in
- RCA Volume 2 page 125
- Author
- Model page created by Ashis Mukerjea. See "Data change" for further contributors.
