• Country
• Canada

• Manufacturer / Brand
• RCA Victor (International), Montreal

• Year
• 1941 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 200533

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• 6SA7 6SK7 6SQ7 6AD7G 6F6G 5Y4G

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast plus more than 2 Short Wave bands.

• Details
• Record Player (perh.Changer)

• Loudspeaker
• Permanent or electro-dynamic (moving coil), system not known yet.

• Material
• Wooden case

• from Radiomuseum.org
• Model: VR-59 - RCA Victor International,

• Shape
• Console with any shape - in general

• Dimensions (WHD)
• 34.69 x 32.5 x 17.31 inch / 881 x 826 x 440 mm

• Notes

• 4 bands.

  This musiccenter has an automatic record changer for 10" and 12" records,  push-pull output amplifier of 5 W, 12" speaker, avc, magic eye, automatic tone compensation.

  It was shown in the RCA prospectus B-5002-7-41VR-60 of 1941 but no price was given at that time in the corresponding pricelist 1939-8-41 .

• Source of data
• Pre-War Consoles

• Mentioned in
• -- Original prospect or advert

• Author
• Model page created by Hans-Joachim Korn † 16.11.15. See "Data change" for further contributors.
