• Country
• Chile

• Manufacturer / Brand
• RCA, Corporacion de radio de Chile S.A.; Santiago de Chile

• Year
• 1950 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 124266

• Number of Tubes
• 10

• Valves / Tubes
• 6BA6 6BA6 6BE6 6AU6 6V6 6V6 6AV6 6AV6 6U5 5Y3

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz

• Wave bands
• Broadcast plus more than 2 Short Wave bands.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• 2 Loudspeakers / Ø 7 inch = 17.8 cm

• Power out
• 10 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Panoramic Sound 9A61 - RCA, Corporacion de radio de

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 680 x 410 x 310 mm / 26.8 x 16.1 x 12.2 inch

• Notes
• Modelo con Onda Media y 5 Ondas Cortas en bandas ensanchadas de 16, 19, 25, 31 y 49 mts. Etapa de audio con salida push-pull y conexión para tocadiscos.

• Net weight (2.2 lb = 1 kg)
• 14 kg / 30 lb 13.4 oz (30.837 lb)

• Source of data
• - - Data from my own collection

• Author
• Model page created by Leonardo Ruz. See "Data change" for further contributors.

• Other Models

• Here you find 67 models, 65 with images and 18 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from RCA, Corporacion de radio de Chile S.A.; Santiago de Chile
