• Country
• Italy

• Manufacturer / Brand
• RCF; Reggio Emilia (AEB Industriale s.r.l., dBtechnologies)

• Year
• 1978 ?

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 264624

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 110 / 220 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Echt-Zeit Spektrum Analysator AF-SA 1 - RCF; Reggio Emilia AEB

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 188 x 482 x 217 mm / 7.4 x 19 x 8.5 inch

• Notes

• Spektral-Analyser in Echtzeit für den NF-Bereich 40Hz-16kHz,

  zur Darstellung der Frequenzkurve von Lautsprecher, Bandgerät, Verstärker etc. ,

  27 Spektralanzeigen mit 1/3 Oktav-Abstand,

  23 dB Dynamik pro Anzeige mit 12 LED (insgesamt 324 LED),

  Mikrofon und Line-Eingang, mit jeweils separaten Regler,

  Ausgang mit Rosa-Rauschen 0,2V RMS.

• Net weight (2.2 lb = 1 kg)
• 8 kg / 17 lb 9.9 oz (17.621 lb)

• Mentioned in
• -- Original-techn. papers.

• Author
• Model page created by a member from D. See "Data change" for further contributors.
