AM-FM 3340

Soundesign Corporation; Jersey City, NJ

Data
Forum
Pictures
Collections

  • Year
  • 1975 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 303411

 Technical Specifications

  • Number of Transistors
  • 7
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 50 Hz; 220 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 cm = 3.1 inch
  • Power out
  • 0.5 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: AM-FM 3340 - Soundesign Corporation; Jersey
  • Shape
  • Tablemodel without push buttons, Mantel/Midget/Compact up to 14
  • Dimensions (WHD)
  • 220 x 150 x 78 mm / 8.7 x 5.9 x 3.1 inch
  • Notes

  • Controllo volume - antenna interna in ferrite - power comsuption 5 watt - frequency range: AM 540/1600 kHz - FM 88/108 MHz.

    Made in Hong Kong

  • Net weight (2.2 lb = 1 kg)
  • 0.7 kg / 1 lb 8.7 oz (1.542 lb)
  • Author
  • Model page created by Aldo Andreani. See "Data change" for further contributors.
