• Country
• United States of America (USA)

• Manufacturer / Brand
• Regal; New York (NY)

• Year
• 1947–1954

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 54992

• • Brand: Ultradyne

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 12SA7 12SK7 12SQ7 50L6 35Z5

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• AC/DC-set / 110 - 120 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: 205 - Regal; New York NY

• Shape
• Tablemodel, with any shape - general.

• Notes

• Color= Ivory. See also the similar Regal model 707.

• External source of data
• Ernst Erb

• Source of data
• The Radio Collector's Directory and Price Guide 1921 - 1965

• Circuit diagram reference
• Rider's Perpetual, Volume 19 = 1949 and before

• Mentioned in
• Collector's Guide to Antique Radios 4. Edition

• Literature/Schematics (4)
• Photofact Folder, Howard W. SAMS (Set 26, Date 10/47, Folder 4716-23)

• Other Models

• Here you find 121 models, 72 with images and 87 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
