CR-761
Regal; New York (NY)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Regal; New York (NY)
- Year
- 1948 ?
- Category
- Car Radio, perhaps also + sound player/recorder
- Radiomuseum.org ID
- 55010
-
- Brand: Ultradyne
Service-Unterlagen
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superhet with RF-stage; ZF/IF 456 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 6 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
- Material
- Metal case
- from Radiomuseum.org
- Model: CR-761 - Regal; New York NY
- Shape
- Chassis only or for «building in»
- Notes
- Vibrator for +B
- External source of data
- Ernst Erb
- Circuit diagram reference
- Rider's Perpetual, Volume 19 = 1949 and before
- Mentioned in
- Photofact Folder, Howard W. SAMS (4820-16 Set 50 Folder 16)
