Twin-Tone U353/2
Regentone (Brand) various manufacturers.
- Country
- Great Britain (UK)
- Manufacturer / Brand
- Regentone (Brand) various manufacturers.
- Year
- 1949/1950
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 102036
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 465 kHz
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- AC/DC-set / 200-250 Volt
- Loudspeaker
- 2 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: Twin-Tone U353/2 - Regentone Brand various
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 20.675 x 15.5 x 8.875 inch / 525 x 394 x 225 mm
- Notes
-
A 3 band 5 valve AC/DC mains superhet radio in a figured walnut cabinet with two matched permanent magnet loudspeakers, covering MW (180-550 metres), LW (1000-2000 metres) and SW (16-50 metres). With connections for gramophone pick-up and external loudspeaker. Released in November 1949.
See also the earlier Regentone Twin-Tone U353 model with different valves and the Regentone A353/2 Twin-Tone AC mains version.
- Price in first year of sale
- 25.00 GBP
- External source of data
- Malcolm Bennett
- Literature/Schematics (1)
- Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (997 dated June 23 1951)
- Author
- Model page created by Günther Stabe † 19.8.20. See "Data change" for further contributors.
