• Country
• Germany

• Manufacturer / Brand
• REMA, Fabrik für Rundfunk, Elektrotechnik und Mechanik, Stollberg (Ostd.)

• Year
• 1974–1979 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 112913

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 16

• Semiconductors

• Main principle
• Superheterodyne (common); ZF/IF 460 kHz

• Tuned circuits
• 7 AM circuit(s)     13 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 13 cm = 5.1 inch

• Power out
• 6 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Solo 230 - REMA, Fabrik für Rundfunk,

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 610 x 170 x 240 mm / 24 x 6.7 x 9.4 inch

• Notes

• Getrennte Abstimmknöpfe für AM und FM, abschaltbare Ferritantenne. Gehäusevarianten: Schleiflack, weiß, mattiert (600 Mark), furniert, mattiert (600 Mark), furniert, poliert (620 Mark).

• Net weight (2.2 lb = 1 kg)
• 8 kg / 17 lb 9.9 oz (17.621 lb)

• Price in first year of sale
• 620.00 DM

• Source of data
• - - Data from my own collection

• Mentioned in
• Funkverlag Hein, Service-CD Rema

• Literature/Schematics (1)
• Sortimentskatalog Elektroakustik (DDR, 1979)

• Author
• Model page created by Dieter Erdmann. See "Data change" for further contributors.
