• Country
• United States of America (USA)

• Manufacturer / Brand
• Remler Co. Ltd.; San Francisco

• Year
• 1933 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 125776

• • alternative name: Gray & Danielson || Remler Radio Manuf.

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• 6A7 6F7 41 84

• Main principle
• Superheterodyne (common); ZF/IF 450 kHz

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• Alternating Current supply (AC) / 110-125 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• from Radiomuseum.org
• Model: 40 [early model] - Remler Co. Ltd.; San Francisco

• Notes
• The Remler model 40 can only be from 1933 or 1934 because the tube 6A7 was released in 1933 (eraliest date) and Rider's volume 4 is copyrighted 1934 (latest date).

• Circuit diagram reference
• Rider's Perpetual, Volume 4 = ca. 1934 and before

• Author
• Model page created by Hans-Joachim Korn † 16.11.15. See "Data change" for further contributors.
