Lira - Лира 68
Resprom; Veliko Tarnovo
- Country
- Bulgaria
- Manufacturer / Brand
- Resprom; Veliko Tarnovo
- Year
- 1968
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 226043
- Number of Tubes
- 6
- Number of Transistors
- Semiconductors
- Tr.Gl.=Metal-rectif.
- Main principle
- Superheterodyne (common); ZF/IF 468/10700 kHz
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Details
- Record Player (not changer)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- 2 Loudspeakers
- Power out
- 2.5 W (undistorted)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Lira - Лира 68 - Resprom; Veliko Tarnovo
- Shape
- Console, Lowboy (legs < 50 %).
- Dimensions (WHD)
- 1030 x 720 x 370 mm / 40.6 x 28.3 x 14.6 inch
- Notes
-
Wave Bands:
MW: 520-1600 kHz
LW: 145-350 kHz
SW: 5,8-18 MHz
FM: 64-73 MHz
- Mentioned in
- book "Bulgarian Radio Receivers"
- Author
- Model page created by Simeon Nikolov. See "Data change" for further contributors.
