Revere T-1120
Revere Camera Co.; Chicago (IL)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Revere Camera Co.; Chicago (IL)
- Year
- 1957 ?
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 179087
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 105 -120 Volt
- Loudspeaker
- 2 Loudspeakers / Ø 5.25 inch = 13.3 cm
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: Revere T-1120 - Revere Camera Co.; Chicago IL
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 14 x 9.5 x 13.5 inch / 356 x 241 x 343 mm
- Notes
- The Revere Camera Model T1100 is a dual tracks two speed stereo tape recorder. Single knob control. Tape speeds of 3.75 and 7.5 i.p.s. for recording up to three hours with new long-play tape.
The Revere models T-1100, T-1120 and TR-1200 Tape Recorders share the same SAMS documentation and feature a single three position function knob which performs the electrical and mechanical functions for "Record", "Stop", and "Play" operations. The model TR-1200 is the same as model T-1100 except for the addition of the B199-6 radio tuner sub-assembly. Model T-1120 is the same as model T-1100 except for a built-in-stereophonic head and preamplifier (B199-11) for the lower channel.
- Net weight (2.2 lb = 1 kg)
- 27 lb 0 oz (27 lb) / 12.258 kg
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Date 8-58, Set 410, Folder 15)
- Author
- Model page created by Egon Penker. See "Data change" for further contributors.
