Revere TR-1200

• Country
• United States of America (USA)

• Manufacturer / Brand
• Revere Camera Co.; Chicago (IL)

• Year
• 1957 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 179086

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 8

• Valves / Tubes
• 6BE6 6BA6 6AV6 12AX7 6S4A 6C4 6V6GT 6X5GT

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Alternating Current supply (AC) / 105 -120 Volt

• Loudspeaker
• 2 Loudspeakers / Ø 5.25 inch = 13.3 cm

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: Revere TR-1200 - Revere Camera Co.; Chicago IL

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 14 x 9.5 x 13.5 inch / 356 x 241 x 343 mm

• Notes
• The Revere Camera Model T2000 is a dual tracks two speed tape recorder with integrated radio tune sub-assembly model B199-6.

  The Revere models T-1100, T-1120 and TR-1200 Tape Recorders share the same SAMS documentation and feature a single three position function knob which performs the electrical and mechanical functions for "Record", "Stop", and "Play" operations. The model TR-1200 is the same as model T-1100 except for the addition of the B199-6 radio tuner sub-assembly. Model T-1120 is the same as model T-1100 except for a built-in-stereophonic head and preamplifier (B199-11) for the lower channel.

• Net weight (2.2 lb = 1 kg)
• 27 lb 0 oz (27 lb) / 12.258 kg

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Date 8-58, Set 410, Folder 15)

• Author
• Model page created by Egon Penker. See "Data change" for further contributors.
