TS-725D

Revere Camera Co.; Chicago (IL)

Data
Forum
Pictures
Collections

  • Year
  • 1956 ?
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 344177

 Technical Specifications

  • Number of Tubes
  • 6
  • Number of Transistors
  • 5
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Tape Recorder
  • Power type and voltage
  • Alternating Current supply (AC) / 205 - 220 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • Material
  • Leather / canvas / plastic - over other material
  • from Radiomuseum.org
  • Model: TS-725D - Revere Camera Co.; Chicago IL
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 425 x 270 x 370 mm / 16.7 x 10.6 x 14.6 inch
  • Notes

  • The Revere TS-725D tape recorder has the following features:

    • 2 track monaural.
    • Tape Speeds: 3 3/4 and 7 1/2 ips.
    • Loudspeaker: elliptical, 23 x 16 cm (9" x 6").
    • Same schematic as Revere T-700-D, except that recorder is designed to operate from a power source that supplies 205-220 VAC at 50 cycles per second.
    • The TS-725D is the export version of the Revere T-700-D.
  • Net weight (2.2 lb = 1 kg)
  • 17.5 kg / 38 lb 8.7 oz (38.546 lb)
  • Author
  • Model page created by Vladimir Jirkal. See "Data change" for further contributors.
