Harris Synthesized Channelized HF-SSB Transceiver RF-230S
RF Communications, Inc.; Rochester, N.Y.
- Country
- United States of America (USA)
- Manufacturer / Brand
- RF Communications, Inc.; Rochester, N.Y.
- Year
- 1985
- Category
- Commercial Transmitter & Receiver (TRX not Amateur)
- Radiomuseum.org ID
- 296092
Picture from manual
Old private radio station.
Old private radio station.
Old private radio station.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Transceiver
- Wave bands
- Short Wave (SW only)
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 13,6 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Power out
- 4 W (undistorted)
- Material
- Metal case
- from Radiomuseum.org
- Model: Harris Synthesized Channelized HF-SSB Transceiver RF-230S - RF Communications, Inc.;
- Shape
- Miscellaneous shapes - described under notes.
- Dimensions (WHD)
- 14.7 x 5.2 x 16.3 inch / 373 x 132 x 414 mm
- Notes
-
The RF-230S is a solid-state transceiver operating in the 1.6 to 30 MHz range. Power output is 125 W PEP or average. Frecuency selection is via front panel frequency selector switches or internally programmed channel frequency information, capable of 32 channel simplex operation or 16 channel half-duplex operation. Operating modes include LSB, USB, AM, AFSK and CW.
- Net weight (2.2 lb = 1 kg)
- 25 lb 0 oz (25 lb) / 11.350 kg
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
- Other Models
-
Here you find 18 models, 12 with images and 8 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from RF Communications, Inc.; Rochester, N.Y.
