• Country
• Great Britain (UK)

• Manufacturer / Brand
• RGD (Brand), Radio Gramophone Development Co. Ltd.; Birmingham

• Year
• 1958 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 102159

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 7

• Valves / Tubes
• ECC85 ECH81 EF85 EABC80 EM80 EL84 EZ80

• Main principle
• Superheterodyne (common); ZF/IF 470/10700 kHz; 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)     10 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 200-250 Volt

• Material
• Wooden case

• from Radiomuseum.org
• Model: A112 Receiver 1-12 - RGD Brand, Radio Gramophone

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 530 x 370 x 250 mm / 20.9 x 14.6 x 9.8 inch

• Notes

• The 3-15 and 3-20 are Auto Radiograms using the same chassis.

  Wavebands:

  • LW: 1000 ... 2000 m
  • MW: 187 ... 550 m
  • SW: 17 ... 50 m
  • VHF: 87 ... 100 MHz

• Literature/Schematics (1)
• Radio And Television Servicing books (R&TVS) (R&TVS 1957-58 Ed. Vol V (1956-57) p 226)

• Author
• Model page created by Peter Hoddow. See "Data change" for further contributors.

• Other Models

• Here you find 148 models, 115 with images and 66 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from RGD (Brand), Radio Gramophone Development Co. Ltd.; Birmingham
