Deluxe Stereogram RG211 Ch=GC3

RGD (Brand), Radio Gramophone Development Co. Ltd.; Birmingham

Data
Forum
Pictures
Collections

  • Year
  • 1965 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 176392

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 10
  • Main principle
  • Superheterodyne (common); ZF/IF 470/10700 kHz; 4 AF stage(s)
  • Tuned circuits
  • 6 AM circuit(s)     8 FM circuit(s)
  • Wave bands
  • Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.
  • Details
  • Changer (Record changer)
  • Power type and voltage
  • Alternating Current supply (AC) / 200-250 Volt
  • Power out
  • 5 W (unknown quality)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Deluxe Stereogram RG211 Ch=GC3 - RGD Brand, Radio Gramophone
  • Shape
  • Console with any shape - in general
  • Dimensions (WHD)
  • 60 x 27 x 16 inch / 1524 x 686 x 406 mm
  • Notes

  • Stereo radiogram (mono radio) fitted with Garrard type AT6 record changer unit. Chassis GC3 made by STC.

    Speakers; 2 x 10" bass and 2 x 4" tweeters.
    Space for Tape Deck and record storage.
    Safety pneumatic lid stay

  • Source of data
  • -- Schematic
  • Circuit diagram reference
  • Radio and TV Servicing books (R&TVS) book
  • Literature/Schematics (1)
  • Trader Sheet 1762
  • Author
  • Model page created by Keith Staines. See "Data change" for further contributors.
