- Country
- United States of America (USA)
- Manufacturer / Brand
- Macy's, R.H. Macy & Co.; New York, NY
- Year
- 1932 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 52345
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common)
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC) / 110 Volt
- Loudspeaker
- Permanent or electro-dynamic (moving coil), system not known yet.
- Material
- Wooden case
- from Radiomuseum.org
- Model: MB56 - Macy's, R.H. Macy & Co.; New
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 14 x 11 x 8 inch / 356 x 279 x 203 mm
- Circuit diagram reference
- Rider's Perpetual, Volume 3 = 1933 and before
- Author
- Model page created by Peter Rutishauser. See "Data change" for further contributors.
