• Country
• Germany

• Manufacturer / Brand
• Riefler Clemens; Nesselwang Bayern

• Year
• 1955 ??

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 172995

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 2

• Valves / Tubes
• EF804 ECL80

• Number of Transistors

• Semiconductors
• B250C30 M30-0

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Wire Recorder (or -Player)

• Power type and voltage
• Line / Batteries (any type)

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Various materials

• from Radiomuseum.org
• Model: Diktiergerät D6 - Riefler Clemens; Nesselwang

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 180 x 90 x 240 mm / 7.1 x 3.5 x 9.4 inch

• Notes

• Frequenzbereich: 200 - 5000 Hz

  Das Gerät verwendet Spezial-Kassetten mit Tondraht:

  • Aufnahmezeit: 15 oder 60 min
  • Minutenzählscheibe
  • Grösse: 188 x 60 x 155 mm
  • Gewicht: 180 gr

  Stromversorgung:

  • 110-125 / 220 V AC
  • 6 V DC
  • 6 & 150 V Trockenbatterie (Zerhacker bereits eingebaut)

• Net weight (2.2 lb = 1 kg)
• 3.8 kg / 8 lb 5.9 oz (8.37 lb)

• Source of data
• -- Original prospect or advert
