DAB/FM RDS/SD Digital Portable Radio RecordR

Roberts Radio Co.Ltd., East Molesey, Surrey, UK

Data
Forum
Pictures
Collections

  • Year
  • 2011 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 335084

 Technical Specifications

  • Main principle
  • PLL, Phase-locked loop
  • Wave bands
  • DAB and FM, perhaps with Streaming [DABFM]
  • Details
  • Other Combination - see Notes; Radio with other functions
  • Power type and voltage
  • Batteries / addl. power jack / D: 4 x 1.5 / 7.5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7.5 cm = 3 inch
  • Power out
  • 0.8 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: DAB/FM RDS/SD Digital Portable Radio RecordR - Roberts Radio Co.Ltd., East
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 243 x 145 x 240 mm / 9.6 x 5.7 x 9.4 inch
  • Notes

  • A portable DAB / FM RDS / SD Digital Radio Recorder with PausePlus. With a telescopic aerial, 3.5mm sockets for Headphone and Aux input.

    Specifications:-
    DAB/FM RDS
    Frequency Coverage
     DAB 174.928 - 239.200MHz
     FM 87.5-108MHz
    PausePlus and rewind functions
    Record DAB and FM to a SD card
    MP3/WMA/AAC playback from a SD card
    One Touch Record
    4 record timers (mains only)
    Clock with 4 multi-function alarms (mains only)
    Sleep/snooze/nap functions
    FM RDS station name display
    10 station presets
    Line in socket for iPod/MP3 playback
    Headphone socket
    Battery or mains powered via AC adapter (included)
    Uses 4 x LR20 (D size) or equivalent batteries (not included)

    Ukw (87,5-108MHz) und DAB (Band 3)
    Wiedergabe und Aufnahme auf SD- Karte
    Betrieb mit 4 R20 Zellen oder extern 7,5V

    .

  • Literature/Schematics (1)
  • - - Manufacturers Literature (Operating Instructions Roberts RecordR dated 2011)
  • Author
  • Model page created by Ben Jäpetz. See "Data change" for further contributors.
