- Country
- Great Britain (UK)
- Manufacturer / Brand
- Roberts Radio Co.Ltd., East Molesey, Surrey, UK
- Year
- 1951
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 315536
- Number of Tubes
- 4
- Main principle
- Superheterodyne (common); ZF/IF 472 kHz
- Wave bands
- Broadcast plus 2 Short Wave bands.
- Power type and voltage
- Line / Batteries (any type) / 100-110; 240-250 / 1.5 + 90 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: RMB Export - Roberts Radio Co.Ltd., East
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 320 x 260 x 170 mm / 12.6 x 10.2 x 6.7 inch
- Notes
-
This is an export model of the Roberts RMB with MW (192-570 metres) and 2 SW bands (30-70 metres and 10.5-35 metres).
- Literature/Schematics (1)
- Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (1037 dated April 12 1952)
- Author
- Model page created by Kjell Larsson. See "Data change" for further contributors.
