• Country
• Germany

• Manufacturer / Brand
• Robotron Vertrieb Berlin / Werk Stralsund, VEB (Ostd.)

• Year
• 1987–1990

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 72388

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 6

• Semiconductors
• SF235 SF235 SF235 SF225 SC239

• Main principle
• Superheterodyne (common); ZF/IF 455/10700 kHz

• Tuned circuits
• 4 AM circuit(s)     6 FM circuit(s)

• Wave bands
• Broadcast, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 11 cm = 4.3 inch

• Power out
• 3 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Strela Konkret RR1401 - Robotron Vertrieb Berlin /

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 442 x 110 x 173 mm / 17.4 x 4.3 x 6.8 inch

• Notes
• ICs: A4100D, A210K.
  Die Plastik-Frontblende war auch in grau erhältlich.

• Net weight (2.2 lb = 1 kg)
• 3.5 kg / 7 lb 11.3 oz (7.709 lb)

• Price in first year of sale
• 405.00 Mark

• Source of data
• -- Collector info (Sammler) / Radiokatalog Band 2, Ernst Erb

• Author
• Model page created by Iven Müller. See "Data change" for further contributors.
