Rock Ola 477 Hit Tracker

Rock-Ola Manufacturing Corporation (Rockola); Chicago, IL

Data
Forum
Pictures
Collections

  • Year
  • 1979/1980 ?
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 247829

 Technical Specifications

  • Main principle
  • Audio-Amplification
  • Details
  • Jukebox-Coin operated Phonograph
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • 4 Loudspeakers
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Rock Ola 477 Hit Tracker - Rock-Ola Manufacturing
  • Shape
  • Console with Push Buttons.
  • Dimensions (WHD)
  • 850 x 1100 x 590 mm / 33.5 x 43.3 x 23.2 inch
  • Notes

  • Verstärker Nr. 52280-A, Netzteil Nr. D: 52405-A , Lautsprecher: 12": # 52309; 6": #51809

    Kreditgerät Nr.52225-A, Tonabnehmer: Shure M44, Lampen: cabinet: TL 25W/T12/28" (*)
    amp. + power supply: GE #1829 - Ba9s 28V/70 mA/2W

    Sicherungen: Rectifier P.C. Board: 2x 1A, 2A
    Battery P.C. Board: 500 mA 125VAC Sub-Min Fuse
    Power P.C. Board: 250 mA
    Amplifier: 3A fast; 5A slo-blo
    power supply: USA: 800 + 250 mA, 5A,

    Computer gesteuerte Juke Box

  • Author
  • Model page created by Mario Darmann. See "Data change" for further contributors.
