• Country
• Canada

• Manufacturer / Brand
• Rogers-Majestic, Standard Radio Manufacturing, Rogers Radio Tubes; Toronto

• Year
• 1957 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 297821

• • alternative name: Rogers Radio Tube

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 10

• Valves / Tubes
• 6BA6 6BE6 6BA6 6AT6 6BR5 12AX7 6AQ5 6AQ5 6X4 6X4

• Main principle
• Superhet with RF-stage; ZF/IF 455 kHz; 3 AF stage(s)

• Tuned circuits
• 7 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Details
• Record Player (perh.Changer)

• Power type and voltage
• Alternating Current supply (AC) / 117 Volt

• Loudspeaker
• 3 Loudspeakers

• Power out
• 5 W (undistorted)

• Material
• Wooden case

• from Radiomuseum.org
• Model: R655 - Rogers-Majestic, Standard

• Shape
• Console, Lowboy (legs < 50 %).

• Notes

• The Rogers-Majestic model R655 is a 10-tube combination radio / record changer console. Has internal plate antenna. For 25 or 60 Hz depending on nameplate rating.

• Mentioned in
• - - Manufacturers Literature

• Author
• Model page created by Tom Seeger. See "Data change" for further contributors.
