Empfänger-Messsender AM/FM SMAF-BN41407

• Country
• Germany

• Manufacturer / Brand
• Rohde & Schwarz, PTE; München

• Year
• 1957 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 191120

• • alternative name: Messgerätebau Memmingen || Physikalisch-Technisches Entwicklungslabor Dr. Rohde & Dr. Schwarz

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 12

• Valves / Tubes
• EC81 EB41 EF80 EF42 EAF42 EL41 AZ41 AZ41 EF40 PL81 EL41 85A1

• Main principle
• Radio Frequency Amplification only

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 150; 220 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Empfänger-Messsender AM/FM SMAF-BN41407 - Rohde & Schwarz, PTE; München

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 450 x 300 x 370 mm / 17.7 x 11.8 x 14.6 inch

• Notes

• Frequenzbereiche:
  1,5- 2,4
  2,3- 4,0
  3,6- 6,5
  10- 18
  17- 31
  30,5- 55
  54- 100
  170- 300
  Modulation: AM/FM, eigen und fremd.

  Achtung: in Handbüchern unterschiedlichen Datums finden sich oft etwas abweichende Frequenzbereiche. Wir notieren, wo möglich, die Beschriftung der Geräte.
