Rauschgenerator Noise Generator SKTU BN4151/2/50, ..60, ..75 3...1000 MHz
Rohde & Schwarz, PTE; München
- Country
- Germany
- Manufacturer / Brand
- Rohde & Schwarz, PTE; München
- Year
- 1960 ??
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 74937
-
- alternative name: Messgerätebau Memmingen || Physikalisch-Technisches Entwicklungslabor Dr. Rohde & Dr. Schwarz
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 1
- Valves / Tubes
- 5722
- Number of Transistors
- 3
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 115-235 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Rauschgenerator Noise Generator SKTU BN4151/2/50, ..60, ..75 [3...1000 MHz] - Rohde & Schwarz, PTE; München
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 470 x 195 x 260 mm / 18.5 x 7.7 x 10.2 inch
- Notes
- Rauschgenerator für weißes Rauschen im Frequenzbereich von 3,0 - 1000 MHz. Ausführungen für 50 Ohm (BN 4151/2/50), 60 Ohm (BN 4151/2/60) oder 75 Ohm (BN 4151/2/75). Anzeigebereiche 0 - 8 dB und 0 - 15 dB (1 - 6,5 und 1 - 33 kTo). Signalausgang Dezifix B.
- Net weight (2.2 lb = 1 kg)
- 9 kg / 19 lb 13.2 oz (19.824 lb)
- Mentioned in
- -- Original-techn. papers.
- Author
- Model page created by a member from D. See "Data change" for further contributors.
