RF-Millivoltmeter URV5

• Country
• Germany

• Manufacturer / Brand
• Rohde & Schwarz, PTE; München

• Year
• 1985 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 104540

• • alternative name: Messgerätebau Memmingen || Physikalisch-Technisches Entwicklungslabor Dr. Rohde & Dr. Schwarz

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 230 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: RF-Millivoltmeter URV5 - Rohde & Schwarz, PTE; München

• Dimensions (WHD)
• 241 x 110 x 340 mm / 9.5 x 4.3 x 13.4 inch

• Notes
• DC mit DC Probe; AC von 9 kHz bis 18 GHz; 200 µV bis 1000 V mit Tastteilern 20 dB und/oder 40 dB. Messungen in: Volt, Watt, dBm, dBV, jeweils hochohmig (EMK) oder 50 Ohm oder 75 Ohm; zusätzlich relative Messungen: Delta V, Delta W, Delta %, Delta dB.

• Net weight (2.2 lb = 1 kg)
• 4.4 kg / 9 lb 11.1 oz (9.692 lb)
