SWR Bridge 50 Ohm ZRB2
Rohde & Schwarz, PTE; München
- Country
- Germany
- Manufacturer / Brand
- Rohde & Schwarz, PTE; München
- Year
- 1980 ??
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 260532
-
- alternative name: Messgerätebau Memmingen || Physikalisch-Technisches Entwicklungslabor Dr. Rohde & Dr. Schwarz
Click on the schematic thumbnail to request the schematic as a free document.
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- No Power needed
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: SWR Bridge 50 Ohm ZRB2 - Rohde & Schwarz, PTE; München
- Dimensions (WHD)
- 72 x 57 x 20 mm / 2.8 x 2.2 x 0.8 inch
- Notes
-
SWR-Messbrücke, dient der Messung von Reflexionen bzw. des Stehwellenverhältnisses
(Standing Wave Ratio, SWR) nach Betrag und Phase z.B mit Wobbel-Messplätzen wie Rohde & Schwarz Polyskop SWOB 5.
Frequenzbereich: 5 MHz bis 2500 MHz.
- Net weight (2.2 lb = 1 kg)
- 0.240 kg / 0 lb 8.5 oz (0.529 lb)
- Mentioned in
- - - Manufacturers Literature
- Author
- Model page created by Ottmar Rollmann. See "Data change" for further contributors.
