- Country
- United States of America (USA)
- Manufacturer / Brand
- Roland Radio Corporation; Mount Vernon (NY)
- Year
- 1956 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 297661
Picture from service manual.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 11
- Main principle
- Superhet with RF-stage; ZF/IF 455/10700 kHz
- Wave bands
- Broadcast (BC) and FM or UHF.
- Details
- Record Player (perh.Changer)
- Power type and voltage
- 60 cycles, 117V = 110 -120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 inch = 30.5 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: 10XF2 - Roland Radio Corporation;
- Shape
- Console, Lowboy (legs < 50 %).
- Notes
-
AC operated AM - FM phono combination superheterodyne receiver.
For service information on record changer unit, see similar V-M model 950 Photofact set 216, folder II or record changer manual CM-5.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 316 Folder 13 Dated 5-56)
- Author
- Model page created by Dirk Taekels. See "Data change" for further contributors.
