• Country
• Spain

• Manufacturer / Brand
• Roselson, Acústica Electrónica, S.L.; Barcelona

• Year
• 1960 ??

• Category
• Radio part (not a module)

• Radiomuseum.org ID
• 322290

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 115; 125 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Transformador de Alimentación AL-12+12 W - Roselson, Acústica Electrónica

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 110 x 135 x 105 mm / 4.3 x 5.3 x 4.1 inch

• Notes

• Roselson, Acústica Electrónica, S.L., AL-12+12 W

  Transformador de alimentación para amplificador estéreo de 12+12 W de potencia.

  • Secundario alta: 315 + 315 V @ 180 mA.
  • Secundario filamentos: 3,15 + 3,15 V @ 5 A
  • Secundario rrectificadora: 5 V @ 2 A

• Net weight (2.2 lb = 1 kg)
• 4.250 kg / 9 lb 5.8 oz (9.361 lb)

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
